1999 PME 250to

PME 250to eccentric press, for sale.

Specifications:

Nominal pressure 2500kN

Ram adjustment 140 mm

Ram stroke, adjustable 20...200mm

Stroke rate infinitely variable 25...75/min

Tool installation height for

maximum stroke

bottom and

adjustment at top 560 mm

Table clamping surface (WxD) 1,600 x 1,000 mm

ram clamping surface (WxD) 1,400 x 1,000 mm

Lateral passage (WxH) 890 x 460 mm

Power main motor 37 kW

Height of the machine approx. 3,800 mm

Weight of the machine approx. 28 to
