2025 ITECH ECO-ITC 120

Manufacturer: pro ITECH

Model: ECO-ITC 120

Year of manufacture : 2025

Condition: Used – in operation for approx. 1 month

TECHNICAL DATA

• Unit Type: Air-cooled inverter chiller
• Cooling Capacity: 120 kW (103,181 kcal/h)
• Compressors: 2 x inverter scroll compressors
• Compressor Power: 2 x 12 kW
• Refrigerant Circuits: 2
• Refrigerant: R407C
• Water Inlet / Outlet Temperature: 25 °C / 20 °C
• Absorbed Power: 30 kW
• COP: 3.67
• Sound Level at 10 m: 65 dB(A)
• Electrical Connection: 400 V ±10%, 50 Hz
• Design Ambient Temperature: +33 °C
• Evaporator: shell & tube
• Minimum Water Flow: 19,000 l/h
• Condenser: microchannel, air-cooled
• Fans: 2 x axial, inverter-controlled
• Total Fan Motor Power: 3.36 kW
• Pump: centrifugal, inverter-controlled, 3 kW, max. 200 l/min
• Water Tank: stainless steel, 450 l
• Control: PLC with touch screen
• Control Panel Protection Class: IP 44
• Dimensions (L x W x H): 2,950 x 1,700 x 2,100 mm
• Weight: 550 kg
• Water Connections: 2"
• Frame: galvanized steel, polyester powder coated
