2014 EUROMAC MTX Flex 6

2014 EUROMAC MTX

Punching machine

Type: MTX

Manufacturer: Euromac

Year: 2014

Total hours: 19932

Operating hours: 12452

Pressing force 300 kN (30 t)

Tools A, B, C, D

Number of stations in the turret 6 (size D)

Number of rotary stations 3

Max. number of tools 60of which rotary ones - continuously 360° 30

Maximum punch diameter (size D) – separate 81 mm

The maximum diameter of the punch in the magazine XMTE4M 4 x 31.7 mm

The maximum diameter of the punch in the magazine XMTE6M 6 x 24.0 mm

The maximum diameter of the punch in the magazine XMTE10M 2 x 24, 8 x 12.7 mm

Working range in the Y axis (with Multitool) 1300 mm

Working range in the Y axis (single tool) 1250 mm

Working range in the X axis (with Multitool) 2550 mm

Numerically controlled stroke depth 0.1 – 31 mm

Automatic repositioning of clamps in the X axis up to 10,000 mm

Max. positioning speed in the Y+X axis 80 m/min.

Axis acceleration 10 m/sec²

Number of strokes – ( step 1.0mm ) 1000/minUSB port 6

Weight 7800 kg

Max. jaw opening 11 mm

Max. stroke 31 mm

Power supply 3 x 400 V/50 Hz

Machine power 8.5 kW

Average consumption 4.5 kW

Positioning accuracy  0.05 mm

Repetitive accuracy during forming  0.10 mm

Maximum sheet weight 200 kg

The maximum positioning speed can be used up to a board weight of 80 kg.

Speed ​​reduction to 50% for weights from 100 to 200 kg.

Pneumatic connection 6  1 bar

Air consumption 0.1 Nm/h

Oil filling for the hydraulic system - hydraulic oil 135 l

Dimensions of the machine – 3630x4840x1900 mm

The machine also includes SW RADAN for creating NC code, or production programming directly on the machine.

Rotary heads and various die-cutting tools are also available for the machine.

In very good condition, under power.
