2020 Giardiana DUAL TECH 420 SBC DRY

2020 Giardiana DUAL TECH 420 SBC DRY

Overall dimensions

• Width: 4850 mm
• Length: 4930 mm
• Max height: 2845 mm
• Working height: 900 mm (+/- 50)

Workpiece capacity

• Width: 100–1300 mm
• Length: 100–2800 mm
• Max thickness: 50 mm

Electrical

• Voltage: 400 V
• Motor protection: ATEX3G + PTC
• Total power: 14.5 kW

Paper belt conveyor

• Speed: 1–3 m/min
• Gearbox: S301P 1:8.9 P.71 B3
• Motor: 0.37 kW

Infeed conveyor

• Speed: 2–6 m/min
• Gearbox: VF44FA1100 P63 B5 B3
• Motor: 0.18 kW

Central conveyor

• Speed: 1.5–4.5 m/min
• Gearbox: C323P 1/136 P71 B3
• Motor: 0.37 kW

Outfeed conveyor

• Speed: 2–6 m/min
• Gearbox: VF 44 P 100 P63 B5 B8
• Motor: 0.18 kW

Spray guns

• Quantity: 4
• Model: TT1301 MACH5 UG.09-154 FILTERMEDIA

Spray gun drive system

• Gearbox: C322P 7.2 SK110B B7
• Motor: brushless
• Gun travel speed: 0–120 m/min

Air supply unit

• Intake air flow: 9000 m³/h
• Pre-filters: yes
• Heating coil: optional
• Motor: 2 x 0.55 kW
• Fan: MQ-BC 500 axial

Exhaust / cleaning system

• Exhaust air flow: 9000 m³/h
• Fan: MRLQ 562
• Cleaning unit filters: 4
• Spray zone filters: yes

Pneumatic system

• Compressed air consumption (6 bar): 1600 NL/min
• Connections: 1 x 1/2"
