2007 Agie Agiedrill 20
2007 Agie Agiedrill 20
Utrecht, Netherlands
Description
Agiedrill 20 - Year 2007
- Spindle speed: Up to 40,000 RPM
- Maximum drilling diameter: 0.3 - 3.0 mm (depending on the material)
- Maximum drilling depth: 30 mm
- X/Y/Z axis travel: 200 x 200 x 300 mm
- Table size: 320 x 270 mm
- Rapid traverse rate: 10 m/min
- Tool changer capacity: 8 tools
- Tool change time: 3 seconds (approx.)
- CNC control: Agievision 3
- Power supply: 3-phase, 380 V, 50/60 Hz
- Power consumption: 6 kVA
- Machine weight: 1,200 kg (approx.)
- Dimensions (L x W x H): 1,850 x 1,600 x 2,300 mm
Please note that these specifications may vary depending on the specific model of the Agie Agiedrill 20.
The Agie Agiedrill 20 is a high-precision CNC drilling machine that was manufactured by Agie Charmilles, a Swiss company that specializes in the production of machines for the metalworking industry.
The Agiedrill 20 is designed for drilling small and medium-sized holes in a wide range of materials, including metals, plastics, and composites. It features a high-speed spindle that can reach speeds of up to 40,000 RPM, which allows for fast and precise drilling.
The machine is controlled by a CNC system that can be programmed to drill holes with a high degree of accuracy and repeatability. The system can also be programmed to perform other operations, such as milling, tapping, and reaming, which makes it a versatile tool for various machining applications.
The Agiedrill 20 has a compact design and a small footprint, which makes it ideal for use in small to medium-sized workshops. It is also equipped with advanced features, such as automatic tool change and a tool breakage detection system, which ensure reliable and efficient operation.
Overall, the Agie Agiedrill 20 is a high-quality drilling machine that offers excellent performance and precision, making it a popular choice among manufacturers in various industries.
Find more here - https://www.ucymachines.com/
Specifications
Manufacturer | Agie |
Model | Agiedrill 20 |
Year | 2007 |
Condition | Used |
