2007 HAEUSLER HPR 330 V+H

Manufacturer: HAEUSLER

Model: HPR 330 V+H

Year of Manufacture: 2007

Approximately 10 pallets of tools for round bar processing are included, with diameters of 60.5, 137, 91, 168, 76, 51, 152, 129, etc.

Condition : Machine currently not in use and therefore not fully assembled

Technical Data:

• Maximum bending moment (at 240 N/mm² yield strength): 200–330 cm³
• Number of bending rolls: 3
• Roll arrangement: asymmetric / symmetric
• Roll diameter: 520 mm
• Driven rolls: all 3
• Roll drive: hydraulic
• Working speed: 0–7 m/min, stepless
• Speed compensation between upper and lower rolls: automatic
• Roll rotation reversal: electro-hydraulic
• Adjustable bending rolls: 2
• Adjustment of bending rolls: hydraulic
• Roll position display: digital, 0.1 mm accuracy
• Roll bearings: roller bearings
• Number of pressure roller systems: 2
• Adjustment of pressure roller systems: hydraulic (axial, radial, swivel)
• Control: central, from movable control panel
• Installed power: 30 kW
• Machine weight: 12,000 kg

Power / Voltage:

• Voltage: 3 x 400 V / 50 Hz
• Control voltage: 24 VDC / 50 Hz
• Total power: 30 kW

Dimensions / Weight:

• Footprint: 2.00 m x 2.13 m
• Height: 2.45 m
• Weight: 12,000 kg
