BOA

Technical Parameters

• Impact Chamber Diameter: 1,200 mm (48")
• Number of Screens: 8 units / Design in HARDOX 400
• Rotor Equipment: 1 – 3 pairs of acceleration elements (Hardox 450)
• Rotor Speed: 1,000 – 1,400 rpm
• Inlet Opening (WxL): Approx. 800 x 400 mm
• Drive Type: Power belt (Kraftriemen)

Electrical Specifications

Standard Drive (75 kW @ 1,500 rpm)

• Voltage: 400V / 500V
• Rated Motor Current: 134 A (at 400V) / 107 A (at 500V)
• Fuse Protection: 160 A (at 400V) / 125 A (at 500V)

Optional Drive (with 90 kW Frequency Converter)

• Voltage: 400V / 500V
• Rated Motor Current: 161 A (at 400V) / 129 A (at 500V)
• Fuse Protection: 200 A (at 400V) / 160 A (at 500V)
