2011 Reishauer RZ150

The Reishauer RZ 150 is a high-performance CNC gear grinding machine, widely regarded as an industry standard for high-volume automotive and aerospace gear production.

By 2011, this model was well-established for its two-spindle technology, which allows one workpiece to be ground while the other is being loaded/unloaded, virtually eliminating idle time.

Core Technical Specifications

• Max. Workpiece Diameter: 150 mm
• Module Range: 0.5 – 3.0 mm
• Max. Gear Width: 100 mm
• Max. Helix Angle: ± 40°
• Number of Teeth: 5 – 150
• Max. Grinding Speed: 80 m/s
• Spindle Speed (Workpiece): 0 – 5,200 RPM
