2008 TRAUB TNX 80/65

Manufacturer:TRAUB

Model: TNX 80/65

Year of Manufacture:   2008

Type of Machine : CNC Lathe

Total Power Requirement: 95 kW

Voltage: 400 V, 50 Hz

Machine Weight: approx. 14,000 kg

Machine Dimensions (L x W x H): approx. 5.5 m x 7.8 m x 2.52 m

Floor Space Required: approx. 5.5 m x 7.8 m

Spindle Specifications

• Spindle head DIN 55026: HSP A8 / GSP A6
• Spindle bore diameter: 65 mm
• Maximum spindle speed: 4,300 min-1 (HSP) / 5,000 min-1 (GSP)
• Main spindle motor output: 25.2 / 30.2 kW
• Counter spindle motor output: 17 / 21.5 kW

Turret System

• Turret positions: 4 turrets (positions 1, 2, 3 and 4)
• Turret stroke X-axis: 170 mm
• Turret stroke Y-axis: plus/minus 60 mm
• Turret stroke Z-axis: 600 / 500 / 950 mm
• Number of driven tools per turret: up to 10
• Vertical tool holders DIN 69880: 40 x 63 mm

Linear Tool Carrier

• B-axis: swivelling
• Number of driven tools: 2x2 / 2x2(4)
• Tool holder: PRECI-FLEX ER32 / diameter 60
• Number of linear tool carrier tools: 5 to 8 flexible

Turning Length and Feed

• Maximum turning length: 550 / 900 mm
• Bar feed stroke: 1,000 mm

Drive System

• Main drive: Siemens spindle motor
• Counter spindle drive: Melco spindle motor
• Hydraulics: Sauer Bibus
• Lifting pump: Brinkmann
• Coolant pump: Brinkmann
• Coolant and lubrication system: Grundfos
• Servo drives (WRV axes X and Y): Melco
• Servo drives (WRV axes Z and V): Melco
• Chip conveyor drive: Melco
• Centralised lubrication: Vogel

Additional Equipment

• C-axis for main spindle: Yes
• C-axis for counter spindle: Yes
• Y-axis tool carrier W1, W2, W3, W4: Yes
• Drive for tools on counter spindle: Yes
• Chip conveyor with ejection unit: Yes
• Sorting unit: Yes
• Absorption through counter spindle: Yes
• Workpiece removal without remaining part: Yes
• Workpiece removal with remaining part: Yes
• VATC main spindle: Yes
• VATC counter spindle: Yes
